جديد شاحنة تزفيت الطرق Isuzu Asphalt distributor truck

We Production 3ton to 20tons Asphalt distributor truck.

Chengli Group is the largest special-purpose vehicle manufacturer in China. We can customize ISUZU, FOTON, HOWO, SINO, JAC, SHACMAN, DONGFENG, JMC and other brand trucks according to your needs.

Isuzu 3m3 asphalt distributing truck
Product Name Isuzu Asphalt spreader truck
Volume of Tank 6CBM
Overall Dimension 6200x2200x2650mm
Thickness of Insulation Layer 100mm insulation layer in middle of tank body
Gross Weight 7300kg
Curb Weight 5660kg
Wheelbase 3360mm
Fuel Type Diesel
Engine Euro VI ISUZU 4KH1CN6LB 120HP engine
Transmission Isuzu MSB 5speeds
Axle & Tire 7.00R16
Max speed 100km/h
Bitumen Spray System Options (Please select which type you need when inquiry)
Type Smart Type
Model of asphalt pump QGB680(680L/min)
Origin of asphalt pump China made
Suitable Tank Volume 3CBM
Medium Hot/Dilute/Emulsify asphalt
Hydraulic System Shanxi YUCI
Proportional Valve Taiwan EFBG-03-160-HF
Reversing Valve √
Relief Valve √
Model of Hydraulic Pump CBQ550-L
Model of Hydraulic Motor 05-110-BD31
Radiator RISHENG brand
Control System German Siemens
Control Type Computer smart control, 1-control-1
Operation Person Number 1 persons
Asphalt Nozzle Number 30
Heating Type Heat conducting oil automatically heating
Conducting Oil Hebei,China
Burner Italy G10
Power of Engine 6KW
Spraying Capacity 0.25~3L/min
Spraying Error ±2%
Spraying Width 4.5m
