turning diameter 850 mm
turning length 2000 mm
turning diameter over slide rest 690 mm
control Siemens
type 840 C
Cooling through the spindle 23 bar
centre height 450 mm
spindle diameter in front bearing 200 mm
spindle hollow 128 mm
power capacity 60 kW
turning speeds 7-1800 U/min
Torque 7908 Nm
workpiece weight 4000 kg
tailstock quill diameter 160 mm
tailstock quill taper MT 5
3 jaw chuck Forckrath 600 mm
Tool changer 60
work piece power 30 kW
turning speeds 56-3000 U/min
total power requirement kW
weight of the machine ca. 18 t
dimensions of the machine ca. 6,3x2,4x3,3 m
The machine has been completely overhauled.
Capto C6 milling chuck
Double prism lathe chuck
The machine has many optional accessories that can be purchased separately.

The tech. Data are manufacturer or operator information and therefore non-
binding. We reserve the right to prior sale; Our terms and conditions of sale
apply exclusively.
